DSPACE GmbH DS1104-06 Controller Module

DSPACE GmbH DS1104-06 Controller Module

Product Introduction

DSPACE GmbH DS1104-06 is a real-time rapid prototyping PCI controller module used for control algorithm development and semi physical hardware in the loop simulation.

Product application areas

Prototype development of motor drive control

Simulation testing of new energy converters

Algorithm validation of automotive electronic control system

Robot servo control experiment

Aerospace controller research and development

University Automation Research Platform

Real time simulation testing of power electronics

Performance verification experiment of servo system

Hardware in the loop simulation testing platform

Replacement of spare parts for industrial control testing equipment

Product Features

Onboard independent real-time processor with fast computation response

Integrated AD/DA, encoder, PWM multi-channel I/O interface

Can directly interface with MATLAB/Simulink, automatically compile and download models

Equipped with ControlDesk software, supporting online parameter debugging

PCI board card installation, quick setup of testing system

Product Specifications

Equipped with PowerPC floating-point real-time processor

Multi channel analog, digital, and encoder channels

PCI bus industrial control board specifications

This controller has excellent real-time performance and is convenient for quickly verifying various control algorithms. dSPACE GmbH DS1104-06 is the preferred real-time control module for scientific research and electronic control prototype development

Product imag
