Zeiss 348242-9143-4302 Platform Control Air Cooled PCB

Zeiss 348242-9143-4302 Platform Control Air Cooled PCB

Product Introduction

Zeiss 348242-9143-4302 is a six axis platform control air-cooled PCB for Zeiss optical inspection equipment, responsible for multi axis motion driving and signal processing of the stage.

Product application areas

Control of semiconductor wafer optical inspection platform

High precision coordinate measurement microscope stage control

Chip micro defect scanning device

Material Research Microscopic Testing Instruments

Motion control of optical precision measuring equipment

Servo drive for wafer size detection equipment

Microelectronics precision positioning platform

Replacement of spare parts for semiconductor testing equipment

Industrial high-precision visual inspection equipment

Linkage control of precision optical instrument stage

Product Features

Six axis motion synchronous control, high positioning accuracy

Air cooled cooling design, stable long-term continuous operation

Strict impedance control to reduce high-speed signal interference

Suitable for clean workshops, resistant to dust and electromagnetic interference

Slot type board, easy to disassemble and maintain

Product Specifications

Multi channel servo drive signal channel

Onboard air-cooled cooling components

Compatible with Zeiss optical inspection rack

This PCB can stably control the multi axis movement of precision stages, ensuring optical detection accuracy. Zeiss 348242-9143-4302 is the core platform control board of precision optical detection equipment

Product imag
