NI PXIe-7821R Input/Output Module

NI PXIe-7821R Input/Output Module

Product Introduction

NI PXIe-7821R Input/Output Module

This NI PXIe-7821R input/output module belongs to the R series reconfigurable RIO board, equipped with Kintex-7 FPGA, used to achieve high-speed custom digital signal acquisition and control

Product Features

Comes with 128 bidirectional digital channels with a maximum signal rate of 80MHz

Support multi level logic level software for free switching

On board 512MB DRAM ensures high-speed data caching

FPGA programmable, customizable PWM encoder and other functions

PXIe bus supports point-to-point high-speed data flow between modules

Application Areas

Hardware in the loop HIL simulation testing platform

High speed digital signal acquisition and generation system

Chip error testing equipment

Sensor signal simulation device

Development of Automated Measurement and Control System

Semiconductor equipment signal detection platform

Aviation electronic equipment verification testing

University FPGA Research Experiment Platform

Industrial high-speed timing control system

PXI Test Platform Spare Parts Replacement

NI PXIe-7821R input/output module can be selected for various high-speed custom digital measurement and control scenarios, relying on programmable FPGA to achieve flexible and real-time signal acquisition and control work

Product imag
