KRAUSS MAFFEI MC301 Control Circuit Board

KRAUSS MAFFEI MC301 Control Circuit Board

 Introduction

KRAUSS MAFFEI MC301 Control Circuit Board

The KRAUSS MAFFEI MC301 control circuit board is a specialized main control board for German KraussMaffei injection molding machines, commonly used for replacing spare parts in older models of injection molding machines

Product Features

1 German KRAUSS MAFFEI original control board, exclusively for injection molding machines, is a discontinued spare part

2. Responsible for the process calculation of the injection molding machine, controlling the action flow of injection locking and other actions

3 with signal isolation protection to reduce the impact of electromagnetic interference on operation in the workshop

4-panel slot installation, compatible with Klaus Maffei corresponding control system

5 compatible with MC300 MC302 control board in the same series

6 built-in overcurrent protection to prevent abnormal circuit damage to the core chip of the board

7 with built-in status indicator light, quickly locate process alarm faults on site

8 industrial grade PCB boards, resistant to workshop oil, dust, and vibration environments

Application Areas

1 KRAUSS MAFFEI Injection Molding Machine Process Logic Operation

Signal interaction between the main control board and the hydraulic unit of the IO module

3. Injection mold opening and closing, injection pressure holding action control

4. Maintenance and replacement spare parts for old Klaus Maffei injection molding machines

5 Rubber molding automation production line industrial control spare parts

Storage and processing of production parameters for precision injection molding equipment

7 Injection molding equipment alarm signal collection and feedback output

There is not much stock of this board, most of which are disassembled and inspected parts. Before installing it, check the program version to prevent KRAUSS MAFFEI MC301 control circuit board from running incorrectly and shutting down

Product imag
