OMRON FH-1050 Vision Host Controller

OMRON FH-1050 Vision Host Controller

 Introduction

Introducing the OMRON FH-1050 visual host controller, OMRON FH series visual system host, which is often used for maintenance and replacement of automated production line inspection equipment

Product Features

Up to two industrial cameras can be connected to synchronously capture images and complete multi-directional detection

Equipped with image processing algorithms, supporting size measurement, defect detection, and character recognition

Support EtherCAT high-speed communication, quickly transmit detection results to PLC

Equipped with NPN/PNP bidirectional I/O output, convenient for docking with external actuators

Strong overall stability, continuous and stable testing under workshop dust and vibration environment

Product Specifications

Model OMRON FH-1050 Vision Host Controller

Equipped with a dual core processor, supporting two camera connections

Supports multiple communication interfaces such as EtherCAT and Ethernet

Built in multiple digital input and output channels

Adapt to the standard operating temperature of industrial control cabinets

Application Areas

Appearance defect detection of production line products

Measurement and positioning of component dimensions

Packaging barcode character reading and recognition

Spare parts for visual system maintenance of automation equipment

Robot arm visual guidance matching controller

Overall, this OMRON FH-1050 visual controller has stable image processing and fast communication speed, making it a commonly used spare part for repairing old visual inspection equipment

Product imag
