ETEL DSO-RAC200A-011D Dual Position Controller Rack

ETEL DSO-RAC200A-011D Dual Position Controller Rack

 Introduction

The ETEL DSO-RAC200A-011D dual position controller rack is a high-precision servo motion control installation chassis, commonly used in semiconductor precision platforms.

Product Features

Modular slot design makes it easy to plug and replace controller boards.

Built in backplane communication bus, stable multi axis synchronous signal transmission.

Equipped with forced air cooling, it has good heat dissipation effect after long-term operation.

The module status indicator light is intuitive, making it easy to quickly diagnose faults.

19 inch standard rack, directly placed in the equipment cabinet for installation.

Product Specifications

Model DSO-RAC200A-011D, 4U rack specification.

Compatible with DSCDP series dual position control board.

AC input 200 to 240 volts, output 24 volts DC.

The backplane supports EtherCAT and CANopen communication.

The working temperature range is 0 to 45 degrees Celsius.

Application Areas

Multi axis servo control system for lithography machine wafer stage.

Precision linear motor displacement platform control.

Motion unit of semiconductor testing equipment.

Replacement of old ETEL servo system spare parts.

High precision optical positioning equipment motion cabinet.

This rack is used to centrally place dual position control modules, ensuring multi axis motion synchronization, and is the basic carrier of precision displacement systems

Product imag
