Powerware RSR310200029Y01 Power Distribution Module

Powerware RSR310200029Y01 Power Distribution Module

 Introduction

Powerware RSR310200029Y01 Power Distribution Module

Product Features:

1. Multi channel regulated output design, providing stable multi-channel DC power supply for the equipment main control board, sensors, and execution units, with low voltage ripple control

2. Built in four fold protection for overvoltage, overcurrent, short circuit, and overheating, quickly cutting off the output in case of a fault, protecting the backend precision board from damage

3. Onboard power status monitoring circuit, capable of collecting output voltage and current information, and providing feedback on power operation and alarm signals to the upper computer

4. Metal shielding shell effectively suppresses electromagnetic interference and adapts to the complex electromagnetic environment of multiple RF boards coexisting in semiconductor equipment cabinets

5. Modular hot swappable structure, standard rack installation interface, on-site direct replacement, no need to shut down the whole machine, and extensive disassembly of wires

Product Parameters:

1. Material model: RSR310200029Y01

2. Module type: AC-DC multi-channel distribution power module

3. Input specifications: AC wide voltage input

4. Output: Multiple isolated DC outputs

5. Compatible equipment: Semiconductor process equipment cabinet power supply unit

Application fields:

1. Centralized power supply for internal boards of semiconductor etching and deposition machine cabinets

2. Distribution and supply of vacuum valves, pressure sensors, and motion mechanisms

3. Stabilized power supply for machine I/O modules and communication boards

4. Equipment power circuit status monitoring and fault warning

5. Replacement and maintenance of spare parts for Powerware cabinet distribution power supply

This Powerware RSR310200029Y01 power distribution module is the core of power distribution for equipment cabinets, converting AC power into multiple stable DC channels to ensure continuous and reliable power supply for various control components of the machine,

Product imag
