AMAT 0190-81245 Digital I/O Module

Product Features:

1. Multi channel digital signal acquisition and output, stable transmission of machine switch signals, fast response speed

2. Onboard optoelectronic isolation design effectively isolates interference and protects the main control board from external impact signals

3. After aging screening at the factory, it runs stably and reliably for a long time in the electromagnetic environment of the semiconductor workshop

4. Modular slot installation, easy on-site plugging and replacement, no need to modify the original equipment wiring

5. Comes with a channel status indicator light, making it convenient for engineers to quickly troubleshoot signal channel faults

Product Parameters:

1. Material model: 0190-81245

2. Signal type: digital input/output switch quantity

3. Working power supply: DC24V

4. Communication bus: AMAT machine internal equipment bus

5. Compatible equipment: AMAT Centura series semiconductor process machine

Application fields:

1. Signal acquisition and output control of pneumatic valve switch in etching chamber

2. Control of signal transmission for machine safety interlock circuit

3. Wafer manipulator in place, limit switch signal acquisition

4. Summary of digital signals for vacuum chamber pressure and door status

5. Replacement and maintenance of I/O control spare parts for AMAT Centura machine

This AMAT 0190-81245 digital I/O module is a signal relay unit for machine automation control, responsible for the transmission and reception of various switch signals, ensuring the normal operation of cavity action and safety interlock

Product imag
