TEL 2L81-050174-V1 Printed Circuit Board Product Features

TEL 2L81-050174-V1 adopts multi-layer circuit board technology, with dense wiring to adapt to complex signal transmission of semiconductor equipment

Sinking gold surface technology, pad oxidation resistance, and long-term use in clean workshops are not prone to poor contact

FR4 high TG substrate, resistant to equipment cold and hot cycles, and the board is not easily delaminated or cracked

Full board three proof coating, moisture-proof and dustproof, suitable for clean chamber conditions such as etching and thin film deposition

Multi channel isolation circuit design to isolate electromagnetic signal interference caused by motors and radio frequencies

Standard card slot integrated structure, directly inserted into TEL equipment backplane, easy to disassemble and replace

High precision positioning holes and solder pads, high compatibility with the original factory, no need to modify the circuit for replacement

Integrate multiple sets of digital analog signal channels to coordinate communication between sensors and actuators

Built in overcurrent and electrostatic protection circuits to reduce electrostatic breakdown and component failures

Narrow and compact version, saving installation space inside the cabinet, suitable for high-density electrical control cabinets

Original factory standardized circuit layout, low signal transmission loss, stable process control accuracy

Resistant to conventional vibrations in the workshop, with no open circuit or virtual welding issues in the long-term operation of the production line

Wide temperature working range, continuous and stable operation in 0-45 ℃ environment without losing signal

Reserved standard bus interface, can be connected to TEL main control system without adapter board

Equipped with fault point testing pads, the efficiency of troubleshooting and troubleshooting circuit problems is higher

TEL 2L81-050174-V1 printed circuit board is specially designed for Tokyo electronic semiconductor equipment, with high reliability and easy replacement and maintenance

Product imag
