AVIVA LIN AT71-M4CL8007-BA2 Linear Industrial Camera

AVIVA LIN AT71-M4CL8007-BA2 Linear Industrial Camera

 Introduction

AVIVA LIN AT71-M4CL8007-BA2 Linear Industrial Camera

8192 pixel high-definition linear array CCD photosensitive chip, 7 μ m square pixel, with extremely strong imaging detail resolution

Medium specification Camera Link high-speed interface, 4Tap parallel output, high peak pixel transfer rate

Built in strong light anti glare circuit, no ghosting in high light scenes, suitable for high brightness workpiece surface detection

100% aperture rate photosensitive array, high photosensitive efficiency, excellent signal-to-noise ratio performance in low light environment imaging

Supports 0-24dB continuously adjustable analog gain, 0.04dB fine step, flexible brightness adaptation

8-bit/10bit dual-mode image output, with the ability to switch grayscale sampling accuracy according to detection requirements

Built in flat field correction function, eliminating uneven lens lighting and ensuring uniform grayscale throughout the entire line

Dual working mode of internal trigger and external trigger, capable of synchronously capturing images with the conveying platform and servo

DC12-24V wide voltage single power supply, suitable for general power supply circuits of automation equipment

Integrated metal heat dissipation fin structure, stable temperature rise without thermal drift during long-term continuous scanning

F-type standard lens interface, compatible with various industrial telecentric and macro detection lenses, easy to replace

Serial port parameter control, allowing remote modification of camera parameters such as exposure, gain, trigger, etc

All metal shielded body, resistant to frequency converter, RF electromagnetic interference, stable operation in dust-free workshop

Compact standardized body size, small space occupation for equipment rack installation, easy integration

Original factory aging machine testing, compatible with high-precision surface defect detection production lines for PCB, glass, and film

AVIVA LIN AT71-M4CL8007-BA2 linear industrial camera has high resolution and stable imaging, and is a spare part for high-precision linear array cameras used for visual inspection of coil and sheet surfaces

Product imag
