 Introduction

TELEDYNE HS-S0-12K40-00 Camera Controller Product Features

Introduction: TELEDYNE HS-S0-12K40-00 is a dedicated control unit for the Thales DALSA line scan camera, which controls the imaging and acquisition process of the 12K high-resolution TDI camera.

Suitable for 12000 pixel linear array CCD, with high imaging resolution

Supports up to 90kHz line frequency, high-speed production line data collection without losing frames

Equipped with HSLink high-speed interface, the image transmission bandwidth is sufficient

Supports 256 levels of TDI gear adjustment, providing clear imaging in low light environments

Bidirectional scanning control, switchable positive and negative sensor reading modes

Built in 100x anti glare function to avoid overexposure and distortion of the image

Compatible with TDI and array acquisition modes, flexible debugging

Multiple hardware triggered IO, synchronized docking device motion axis

Built in flat field correction algorithm to unify the brightness and color difference of the image

Software programmable exposure, line frequency, gain and other parameters

Real time image data preprocessing reduces upper level computational pressure

Metal enclosed shell, resistant to electromagnetic signal interference in the workshop

Built in fault self check, quickly identify camera communication abnormalities

Standard industrial installation specifications, easy disassembly and replacement operation

Wide temperature stable operation, suitable for panel and roll detection conditions

Conclusion: TELEDYNE HS-S0-12K40-00 has stable imaging control and is suitable for high-speed precision visual inspection. It is the core control component of industrial line scanning equipment.

Product imag
