SMC NCDQ2B63-45D-XB servo motor module

SMC NCDQ2B63-45D-XB servo motor module

 Introduction

SMC NCDQ2B63-45D-XB Thin Cylinder Product Features

Introduction: SMC NCDQ2B63-45D-XB belongs to the NCQ2 compact thin cylinder, with a small volume and stable output, suitable for various automated push positioning stations.

63mm cylinder diameter, 45mm standard stroke, single rod double acting drive

Ultra thin square body, greatly saving equipment installation space

Four sided magnetic switch slots, flexible sensor installation

Standard installation method with through-hole, easy to disassemble and fix

Built in strong magnetic piston, can be paired with magnetic switch to sense stroke

Bidirectional sealing structure, airtight and not prone to air leakage

Suitable for 1/4 inch NPT air port, convenient pipeline connection

XB dedicated temperature resistance specification, stable operation under wide temperature conditions

Low speed stable output, minimal impact without damaging the workpiece

Aluminum alloy cylinder body, lightweight and rust resistant and wear-resistant

Standard working pressure of 145psi, sufficient output thrust

Multiple types of installation accessories to choose from, suitable for various device structures

Low friction piston, smooth reciprocating motion without jamming

Through RoHS industrial certification, the workshop is durable for a long time

Adapt to the loading and unloading scenarios of assembly lines and fixtures

Conclusion: SMC NCDQ2B63-45D-XB compact cylinder has sufficient thrust and flexible installation, making it a universal pneumatic actuator for automation equipment.
