HAMAMATSU C8779K-01 scanning unit

HAMAMATSU C8779K-01 scanning unit

Product Details Introduction

HAMAMATSU C8779K-01 Scanning Unit Product Features

beginning

HAMAMATSU C8779K-01 Hamamatsu Original Semiconductor Lithography Machine CCD Precision Scanning Unit, with precise imaging and adaptability to wafer lithography detection. The core features are as follows:

Equipped with a dedicated linear CCD photosensitive chip, the imaging is clear under low light conditions

High speed scanning and reading, adapted to the continuous production rhythm of lithography equipment

Integrated optical module, stable and offset free optical path

Metal sealed dustproof shell, suitable for clean workshop environment

Multi channel standard industrial interface, directly connected to the main control system of the lithography machine

Built in electronic shutter, precise synchronization of workpiece scanning timing

Anti halo circuit design, no image overflow phenomenon in high light areas

Low dark current design, low noise during long-term scanning

Integrated heat dissipation structure, continuous operation with controllable temperature rise

Multiple overvoltage and electrostatic protection to prevent damage to photosensitive components

Standardized installation base, easy disassembly and calibration operation

Layered signal routing to resist electromagnetic interference in the workshop

Original factory precise calibration, minimal imaging positioning error

Compatible with Nikon series stepper scanning lithography machines, high compatibility

Modular split structure, separate replacement and repair of faulty components

ending

HAMAMATSU C8779K-01 scanning unit has stable imaging and reliable protection, and is a high-precision optical scanning accessory specifically designed for semiconductor lithography equipment.

Product imag
