AMAT 0100-A4390 Central Controller Module

AMAT 0100-A4390 Central Controller Module

Product Details Introduction

AMAT 0100-A4390 Central Controller Module Product Features

Introduction: AMAT 0100-A4390 is a central control module dedicated to semiconductor equipment, compatible with etching and thin film deposition process platforms, with stable computation and high integration. Its core features are as follows:

Equipped with industrial grade main control chip, fast command response speed, precise process timing control

Multi channel mixed digital/analog I/O channels, capable of synchronously collecting chamber pressure and temperature signals

Equipped with Ethernet and RS485 dual communication interfaces, supporting Modbus industrial networking protocol

Suitable for 100-240V wide AC power supply, stable operation under fluctuating power grid conditions

Working temperature range -10 ℃ to 60 ℃, suitable for long-term closed working environment of production line cabinets

Analog signal acquisition accuracy ± 0.2%, meeting the requirements of nanoscale semiconductor process control

Integrated overvoltage, overcurrent, and overtemperature triple hardware protection, automatic sound and light alarm for abnormal situations

Metal reinforced PCB board layer, anti vibration, anti cavity electromagnetic radiation interference

Large capacity program storage, capable of storing multiple sets of production process parameters with one click switching

Built in multi-dimensional fault self checking program, quickly locate the fault points of circuits and components

Standard modular plug-in structure, easy disassembly and assembly, reducing equipment downtime for maintenance

Compliant with CE and RoHS industry certifications, the dust-free workshop uses compliant and pollution-free materials

Support remote online debugging and data uploading, facilitating centralized monitoring and management of the production line

Compatible with all AMAT Centura and Endura process equipment, with strong versatility for replacement

Low power operation design, 24-hour uninterrupted full load operation, less prone to heating and aging

Conclusion: In summary, AMAT 0100-A4390 combines the advantages of high-precision control, strong anti-interference, and easy maintenance, and is the core control component of semiconductor vacuum process equipment.

Product imag

ontroller Module
