Product Details Introduction

ADAS PMC FREQ frequency measurement/counting PMC daughter card

beginning

ADAS PMC FREQ frequency measurement/counting PMC daughter card is compatible with PMC standard slot, used for ADAS equipment pulse signal acquisition, frequency calculation and pulse counting, with accurate and stable measurement data.

Multi channel independent pulse acquisition, with no crosstalk between channels

Wide range frequency detection, suitable for various sensing pulse signals

High precision counting chip, pulse statistics without loss error

Equipped with photoelectric isolation to block external high-voltage electromagnetic interference

Integrated filtering circuit, filtering out on-site clutter interference signals

Multi hardware protection design for overvoltage, overcurrent, and static electricity

Standard PMC specification, can be directly embedded into the industrial control motherboard slot

Onboard status indicator light, visually viewing the working status of the channel

Industrial wide temperature element device, suitable for high and low temperature working conditions of equipment

Low power circuit design, less likely to generate heat during long-term operation

Support adaptive recognition of high and low level pulses without the need for debugging

Real time data upload, synchronized output of counting and frequency data

Power on automatic self check, quickly locate channel circuit faults

Standard terminal interface, easy to connect with speed and displacement sensors

Single channel fault isolation, does not interfere with the collection work of other channels

ending

ADAS PMC FREQ frequency measurement/counting PMC daughter card has high measurement accuracy and strong compatibility, meeting the requirements of ADAS system pulse frequency acquisition and counting control.
