ADAS ICV150/D differential analog acquisition card

beginning

The ADAS ICV150/D differential analog acquisition card is specially designed for in vehicle ADAS sensing signal acquisition. The differential input structure effectively suppresses common mode interference and collects accurate and reliable data.

Differential input acquisition architecture significantly reduces common mode noise in the circuit

Multi channel synchronous sampling, synchronous reading of multiple sensing signals

High precision analog-to-digital conversion, unbiased acquisition of weak analog signals

Onboard isolation protection, isolating high voltage circuit interference and crosstalk

Built in EMI filtering circuit, suitable for complex electromagnetic environments in vehicles

Multiple hardware safety protections against overcurrent, overvoltage, and static electricity

Support vehicle wide voltage power supply, stable operation with voltage fluctuations

Independent channel status light, quickly identify faulty channels

Industrial grade wide temperature element device, suitable for high and low temperature environments inside vehicles

Low power circuit design, lower temperature rise during long-term operation

Standard terminal wiring, compatible with various ADAS sensors

Power on self-test function, pre check for short circuit issues in the circuit

Linear signal conditioning, smooth and undistorted sampling output

Small board size, easy to install in vehicle equipment compartment

Single channel independent operation, local faults do not affect the overall data collection of the machine

ending

The ADAS ICV150/D differential analog acquisition card has outstanding anti-interference ability and is the core board for high-precision analog signal acquisition in vehicle ADAS.
