ADAS ICV726 Analog Output/Communication Isolation Card

ADAS ICV726 Analog Output/Communication Isolation Card

Product Details Introduction

ADAS ICV726 Analog Output/Communication Isolation Card

beginning

ADAS ICV726 analog output/communication isolation card is adapted to the onboard ADAS control system, balancing analog signal output and communication isolation functions to ensure safe and stable signal transmission throughout the vehicle.

Multiple standard analog output channels with high linearity of signal output

Communication circuit independent optoelectronic isolation, blocking high and low voltage interference and crosstalk

High precision DA conversion chip with minimal output numerical error

Integrated multi-level EMC filtering to suppress electromagnetic interference clutter inside the vehicle

Four fold hardware protection against overvoltage, overcurrent, static electricity, and reverse connection

Support car 12V wide voltage power supply, suitable for voltage fluctuation conditions

Dual channel status indicator light, distinguishing communication and output faults

Industrial wide temperature element device, capable of withstanding temperature differences inside the vehicle

Low power circuit design, low heat generation during long-term operation

Standardized terminal interface, convenient wiring disassembly and maintenance

Power on automatic self check, quickly locate channel circuit abnormalities

Compact board size, easy to install in vehicle equipment compartment

Analog signal with adjustable gain, suitable for different actuators

Compatible with ADAS peripherals such as radar and visual controllers for communication

The channels are independent of each other, and a single fault does not affect the other channels

ending

ADAS ICV726 analog output/communication isolation card has strong isolation performance and high output accuracy, meeting the needs of analog output and communication isolation in vehicle ADAS systems.

Product imag
