ADAS STB 504 Bus Signal Expansion Board

ADAS STB 504 Bus Signal Expansion Board

Product Details Introduction

ADAS STB 504 Bus Signal Expansion Board

beginning

The ADAS STB 504 bus signal expansion board is extended to the on-board ADAS bus, expanding multiple bus channels and solving the problem of insufficient device bus interfaces.

Multi channel bus expansion channel, effectively increasing the number of original vehicle bus interfaces

Support CAN and CAN FD mainstream vehicle bus signal transmission

Channel electrical independent separation, signal transmission without mutual interference

Built in photoelectric isolation module to isolate high and low voltage circuit interference

Integrated EMC filtering circuit to weaken electromagnetic clutter interference inside the vehicle

Multi layer protection circuit for overvoltage, overcurrent, static electricity, and anti reverse connection

Suitable for car 12V wide voltage power supply, stable operation with voltage fluctuations

Single channel independent indicator light for quick troubleshooting of bus communication faults

Industrial wide temperature element device, suitable for the variable temperature difference environment inside the vehicle

Low power circuit architecture, long-term operation with low temperature rise and no overheating

Small board design, space saving installation inside the car's electrical control box

Standard plug-in terminal block, easy to disassemble and repair

Signal lossless forwarding, with no attenuation in bus speed after expansion

Compatible with cameras, millimeter wave radar, and various ADAS sensors

Single channel circuit breaker protection, one fault does not affect other channels

ending

The ADAS STB 504 bus signal expansion board has strong expansion capability and complete protection, effectively compensating for the shortage of bus interfaces in on-board ADAS equipment.
