ADAS STB306 bus signal conditioning board

ADAS STB306 bus signal conditioning board

Product Details Introduction

ADAS STB306 bus signal conditioning board

beginning

The ADAS STB306 bus signal conditioning board is used for vehicle ADAS bus signal noise reduction, level adaptation, multi-channel synchronous conditioning, and ensuring stable transmission of sensor data.

Multiple independent signal conditioning channels with no crosstalk between channels

Adapt to CAN and CAN FD vehicle bus signal processing

High precision level conversion, matching with on-board sensor voltage

Built in multi-level EMC filtering to suppress electromagnetic clutter inside the car

Optoelectronic isolation circuit, isolating high and low voltage circuit interference

Four fold protection against overvoltage, overcurrent, static electricity, and reverse connection

Vehicle wide voltage power supply, compatible with 12V vehicle power system

High speed signal processing, no data transmission delay distortion

Onboard status indicator light, visually viewing the working status of the channel

Industrial grade wide temperature device, capable of withstanding temperature differences inside the vehicle

Small and compact board body, equipment compartment installation saves space

Low power circuit, low heat generation during long-term operation

Standard plug-in terminals, easy and fast wiring maintenance

Compatible with various cameras, radar ADAS peripherals

Power on automatic self check, quickly troubleshoot circuit faults

ending

The ADAS STB306 bus signal conditioning board has excellent filtering and isolation performance, and can stably regulate various bus signals of on-board ADAS.
