ADAS 16.86121-0007 Index Control Board

ADAS 16.86121-0007 Index Control Board

Product Details Introduction

ADAS 16.86121-0007 Index Control Board Product Features

beginning

ADAS 16.86121-0007 index control board is compatible with Roland printing equipment VME bus system, accurately completes index positioning signal acquisition and logic control, and runs stably to adapt to production line conditions.

Exclusive index positioning operation unit, precise control of equipment indexing actions

Compatible with standard VME bus slots, can be directly mounted on industrial control racks

Multiple independent signal acquisition channels, synchronously reading position sensor data

Onboard electrical isolation circuit to isolate electromagnetic interference from equipment motors

Built in multiple hardware protections against overcurrent, overvoltage, and short circuit

Industrial grade wide temperature element device, suitable for high and low temperature environments in workshops

Equipped with status indicator lights, quickly diagnose communication and channel faults

High speed signal processing chip, shortening the response delay of index instructions

Standardized board size, easy and convenient disassembly and maintenance

Support local storage of point parameters, data will not be lost during power outages

Optimization of filtering circuit to eliminate interference from on-site clutter signals

Adapt to the complete set of index linkage program for original printing equipment

Low power circuit design, not prone to overheating and aging during long-term operation

Multiple standard terminal interfaces for connecting encoders and actuators

Support fault self checking function, quickly locate abnormal points in the channel

ending

ADAS 16.86121-0007 index control board has precise positioning and strong compatibility, and is the core supporting control board for the index transmission system of printing equipment.

Product imag
