ADAS RCV-20/20-5R dual channel redundant control board

beginning

The ADAS RCV-20/20-5R dual channel redundant control board features dual backup control to ensure uninterrupted and stable operation of the onboard ADAS system, avoiding the risk of single channel failure shutdown.

Dual channel fully independent redundant architecture, seamlessly replacing one faulty channel with the other

Dual channel synchronous data acquisition, real-time comparison and verification of signal data

Built in hardware fault automatic switching chip, switching without delay

Electrical isolation partition design, two circuits do not interfere with each other

Multiple overvoltage, overcurrent, static electricity, and anti reverse protection

Suitable for car 12V wide power supply, stable operation with voltage fluctuations

Onboard multi-channel status indicator lights to distinguish channel operation faults

Industrial wide temperature element device, suitable for high and low temperature working conditions inside the vehicle

Equipped with EMC anti-interference circuit to resist vehicle electromagnetic noise

Standard plug-in interface, easy disassembly and maintenance operation

Low power circuit design, low heat loss during long-term operation

Compatible with ADAS sensing devices such as radar and cameras

Equipped with power on self-test, quickly identify channel abnormalities

Support fault record storage for easy maintenance and troubleshooting in the later stage

Compact board specifications, suitable for narrow installation positions of on-board equipment

ending

ADAS RCV-20/20-5R dual channel redundant control board has reliable switching and comprehensive protection, providing dual operation guarantee for on-board ADAS equipment.

Product imag
