Bobst 704-1257-02 Motor Control Board

Bobst 704-1257-02 Motor Control Board

Product Details Introduction

Bobst 704-1257-02 Motor Control Board

1. Matching Bobst complete processing equipment, precise control of matched drive motor start stop and speed regulation

2. Built in current closed-loop control circuit ensures stable speed without sudden changes when the motor load changes

3. Integrated overcurrent, overload, and overheating triple protection, cutting off output protection components in case of stalling

4. Gold plated plug-in terminals, dust-proof and moisture-proof, reliable long-term contact with workshop oil pollution environment

5. Equipped with filtering circuit to weaken the electromagnetic interference of the frequency converter and avoid control signal disorder

6. Wide temperature working range, sustainable long-term continuous operation of high and low temperature workshop environment

7. Standard board specifications, card slot direct insertion installation, old board can be replaced in situ without changing wiring

8. Partition circuit wiring, single motor failure does not interfere with other drive branches

9. Onboard fault indicator light, visually lit for overload abnormalities, reducing maintenance time

10. Prefabricated firmware from the original factory, no programming or debugging required for installation, and can be put into use immediately after power on

11. High precision PWM voltage regulation output, controlling motor operation accuracy, improving machining yield

12. Moisture resistant solder mask PCB substrate, resistant to dust and ink erosion, delaying circuit aging

13. Factory full load aging test shows low machine failure rate and longer service life for the entire machine

14. Compatible with drive motors of the same model series, with good interchangeability of equipment spare parts and universality

15. Anti static grounding design to prevent unnecessary shutdown caused by static breakdown of chips

The Bobst 704-1257-02 motor control board is the core main control component for the power drive of Bobst equipment

Product imag
