BOBST LSO-8010 Printed Circuit Board

BOBST LSO-8010 Printed Circuit Board

Product Details Introduction

BOBST LSO-8010 Printed Circuit Board

BOBST LSO-8010 is a dedicated signal drive board for Mouvent series box pasting machines, which controls the sensing and valve group signals of the paper feeding station.

1. Multiple sets of wiring terminals, directly connected to on-site photoelectric and solenoid valve components

2. LSO-8010 comes with photoelectric isolation to isolate strong and weak electrical interference

3. Three proof coating on the board, resistant to ink, dust, and humid environment in the workshop

4. Gold plated plug-in socket, less prone to poor contact during equipment vibration

5. Built in overload protection circuit, external short circuit automatic locking protection

6. Partition routing layout to weaken electromagnetic interference between lines

7. Original industrial components, stable operation under high and low temperature conditions

8. Onboard status indicator light, quick troubleshooting and location of fault points

9. Standard card mounting specifications, no need to change wires for in-situ insertion and replacement

10. Single channel independent circuit, single point failure, incomplete board shutdown

11. Simple cache chip, automatically matches machine parameters upon startup

12. Reinforce PCB substrate to withstand continuous start stop vibration of equipment

13. Low power circuit, long-term mass production with low heat generation and slow aging

14. Original factory bus protocol, matched with the same series of main control interface boards

15. BOBST LSO-8010 is compatible with Bosch Mouvent's full range of laminating equipment

Applicable model: Bosch Mouvent fully automatic high-speed box pasting machine electronic control unit.
