Ansaldo 167A.0100009 power driver board

Ansaldo 167A.0100009 power driver board

Product Details Introduction

Ansaldo 167A.0100009 is a power driver board for the ASIRobicon DC speed control/excitation system, belonging to the SPDM/SPDME/SPAE series core power supply and drive components, responsible for system power generation, power drive amplification, and fault protection.

System level power supply: Convert input AC power into multiple stable DC channels (± 15V/24V/5V) for the operation of the entire board.

Power driven amplification: drives thyristor/IGBT power devices to output sufficient current to drive excitation and main circuit.

Wide voltage input adaptation: Suitable for 380V/415V/440V power frequency, compatible with power grid fluctuations.

Multiple overcurrent protection: hardware fast melting+current closed-loop limitation, protecting power components.

Overvoltage/undervoltage monitoring: Real time monitoring of bus voltage, blocking output and alerting in case of abnormalities.

Soft start control: Slowly increase voltage, suppress surge current, and extend device life.

Strong and weak electrical isolation: The power side and control side are optically isolated, resistant to EMI and ground current interference.

Industrial grade PCB: FR-4 gold-plated board, thickened copper foil, strong high current carrying capacity.

Wide temperature operation: -25 ℃~+75 ℃, suitable for harsh working conditions in metallurgy, rolling mills, and power plants.

Onboard status LED: power ready, normal drive, fault light, quickly locate issues.

Reinforced three proof coating: moisture-proof, dust-proof, and corrosion-resistant, suitable for high dust/humid environments.

Standard card slot installation: original hole position, plug-in design, replacement without complex debugging.

Compatible with all models: compatible with PR50A/PR66A/PU50A/PU66A and other power board systems.

Factory full load aging test: 100% load test, high stability and consistency.

Original compatible replacement: The model is completely matched and can be directly replaced with 167A.0100009.

The Ansaldo 167A.0100009 power drive board is the "power heart" of the speed regulation device, directly determining the system stability and load capacity.

Product imag
