1394-AM75 servo drive

1394-AM75 servo drive

Product Details Introduction

1394-AM75 (Allen Bradley) servo drive

1394-AM75 is a Rockwell Allen Bradley 1394 series high-power AC servo shaft module with DC bus input and single axis drive. It features high precision, high torque, and high-speed dynamic response, and is used for mid to high end multi axis motion and heavy equipment.

Model: 1394-AM75 (Bulletin 1394), high-power servo shaft module.

Input: DC bus 530-680V, compatible with 400/480V three-phase rectifier bus.

Power: Rated 17.8-23.8kW, continuous current 35A, peak current 70A (1s).

Drive type: IGBT PWM, compatible with AB 1326/1390 series AC servo motors.

Control mode: Position/speed/torque closed-loop, DSP full digital, current loop at 100 μ s level.

Feedback interface: Standard incremental encoder, optional absolute encoder.

Communication: Supports SERCOS, DeviceNet, analog ± 10V, pulse direction.

Protection: overcurrent, overvoltage, undervoltage, overheating, short circuit, stall, encoder fault protection.

Accuracy: Speed fluctuation * *<0.05%, positioning accuracy ± 1 pulse * *, suitable for precise positioning.

Dynamic: High bandwidth, fast response, supports high-frequency start stop and fast commutation.

Heat dissipation: Built in heat sink, wide temperature range of 0-50 ℃, suitable for cabinet installation.

Structure: Modular, IP20 protection, rail mounted, supports multi axis splicing.

Efficiency: ≥ 98%, low loss, energy-saving operation.

Diagnosis: Built in fault codes, real-time monitoring, and support for upper computer diagnosis.

Applications: CNC machine tools, robots, packaging, textiles, papermaking, heavy-duty multi axis equipment.
