6FC5103-0AB03-0AA2 Control Panel

6FC5103-0AB03-0AA2 Control Panel

Product Details Introduction

6FC5103-0AB03-0AA2 is a 9.5-inch color CNC control panel for Siemens Sinumerik 840C/840CE system, which integrates a full keyboard and display unit, and is the core component of machine tool human-computer interaction.

1. Model: 6FC5103-0AB03-0AA2, Sinumerik 840C/840CE dedicated integrated operation panel.

2. Display: 9.5-inch color CRT monitor, graphical interface, clear display of processing parameters and machine status.

3. Keyboard: Integrated full-featured CNC keyboard (including 2 touch keys), supporting program editing, parameter setting, and manual operation.

4. Power supply: AC 115/230V adaptive (50/60Hz), built-in 6FC5147-0AA14-0AA1 power module.

5. Power: Approximately 62VA, low-power design, compatible with the power supply capacity of CNC cabinets.

6. Integrated interface: Comes with a built-in panel interface board, directly connects to the CNC host, simplifying system wiring.

7. Installation: 19 inch standard rack mounted, ultra-thin (SLIMLINE) structure, embedded in the machine console to save space.

8. Protection: The front panel is IP20, dust-proof and anti misoperation, suitable for industrial environments in workshops.

9. Temperature: 0 ° C to+40 ° C operating temperature, suitable for conventional machine tool workshop conditions.

10. Durability: Industrial grade buttons, anti fatigue design, support millions of presses, long-term high load stability.

11. Compatibility: Perfectly compatible with Sinumerik 840C/840CE CNC system, plug and play.

12. Function: Supports automatic/manual/editing/diagnostic modes, integrated alarm display and fault diagnosis interface.

13. Anti interference: EMI shielding design to resist strong electromagnetic interference from machine tools, ensuring stable display and operation.

14. Material: Metal panel reinforced structure, earthquake and impact resistant, suitable for machine tool vibration environment.

15. Application: Widely used in Siemens 840C/840CE CNC machine tools such as machining centers, lathes, milling machines, etc.

Core advantages: Color display+full keyboard+integrated design, it is a classic and highly reliable operation panel for the 840C system.
