Product Details Introduction

6EV3055-0DC (often written as ODC) is a dedicated power module for Siemens Sinumerik series CNC systems, providing stable DC power supply for machine tools/CNC units. It is designed with industrial grade reliability and long lifespan.

1. Model: 6EV3055-0DC, Siemens Sinumerik CNC platform dedicated power supply.

2. Input: AC 115/230V adaptive, wide voltage compatible with global industrial power grids.

3. Output: Multiple DC voltage regulators (including+5V, ± 15V,+24V) provide power to the CNC CPU, I/O, and drivers.

4. Power: Approximately 150W at full load, suitable for powering small and medium-sized CNC systems.

5. Conversion efficiency: Efficient switching power supply, low power consumption, low heat generation, stable long-term operation.

6. Protection function: Full protection against overvoltage, undervoltage, overcurrent, short circuit, and overheating, and automatic fault shutdown to prevent damage.

7. Industrial grade anti-interference: EMI filtering, strong isolation, suitable for strong electromagnetic environment of machine tools.

8. Structure: Metal shielding shell, reinforced PCB, resistant to vibration and impact.

9. Installation: Standard guide rail/screw fixation, compatible with Siemens CNC cabinet installation dimensions.

10. Heat dissipation: Natural air cooling, fanless design, dust-proof and maintenance free, long service life.

11. Temperature range: 0 ° C to+55 ° C, suitable for high and low temperature working conditions in the workshop.

12. Compatibility: Compatible with Sinumerik 810/820/840 series CNC system racks.

13. Redundancy: Supports dual power redundancy configuration to enhance the continuous operation capability of the CNC system.

14. Certification: CE, UL, CSA, compliant with industrial equipment safety and EMC standards.

15. Application: Widely used in Siemens CNC machine tools such as machining centers, lathes, milling machines, etc.

6EV3055-0DC is the core power supply unit of Sinumerik CNC system with multi-channel voltage regulation, full protection, and maintenance free.

Product imag
