PC-ACR8020-03 servo drive

PC-ACR8020-03 servo drive

Product Details Introduction

PC-ACR8020-03 servo drive

PC-ACR8020-03 is a Parker ACR8020 series multi axis servo drive/motion control card, based on PCI bus, used for multi axis synchronous control of high-end automation equipment.

Brand: Parker (Parker, USA)

Model: PC-ACR8020-03 (ACR8020)

Type: PCI bus servo drive/motion control card

Control axis number: standard 8 axes, expandable to 16 axes

Core processor: 120MHz 32-bit floating-point DSP, with a processing speed of 120MFLOPS

Control mode: pulse/direction, DAC analog output, compatible with servo/stepper motor

Encoder interface: 10 channels of 20MHz high-speed counting (expandable to 20 channels)

Analog input: up to 8 channels, 12/16 bit resolution

Bus: Standard PCI, compatible with industrial computer installation

Control frequency: current loop 12kHz, position/velocity loop 4kHz

Trajectory planning: supports S-curve, T-curve, PVT mode

Synchronization function: multi axis coordination, electronic gear, cam synchronization

Protection mechanism: overcurrent, overvoltage, overheating, short circuit, encoder abnormality

Programming environment: Supports Parker Motion language, C/C++/VB libraries

Applications: CNC machine tools, robots, semiconductor equipment, precision automation production lines

Product imag
