Westinghouse 3A99200G01 Controller Slot Rack Backboard

Westinghouse 3A99200G01 Controller Slot Rack Backboard

Product Details Introduction

Westinghouse 3A99200G01 Controller Slot Rack Backboard

Westinghouse 3A99200G01 is the PCI bus controller rack backplane of Emerson Ovation DCS system, providing physical slots, high-speed interconnection and power distribution for controllers, I/O and communication cards, and serving as the core hardware carrier of the system.

Specially designed for Ovation controller rack, used in conjunction with 3A99199G01 power backplane.

Adopting 32-bit/33MHz industrial PCI bus to ensure high-speed data transmission between cards.

Provide 7-10 standard PCI slots (including controller specific slots), compatible with Ovation's full range of PCI cards.

Powered by 3A99199G01, supporting redundant power input to enhance power supply reliability.

Backplane impedance matching and signal integrity optimization, strong resistance to electromagnetic interference (EMI).

Standard Ovation rack installation, metal structure, compatible with system cabinets.

Compatible with 3A99200G02 equivalent series backboards, seamlessly compatible with Ovation system software.

Support hot plugging (requires card and system coordination), online maintenance does not affect operation.

Industrial grade PCB and gold-plated contacts ensure long-term stable operation.

Working temperature range of * * -20 ℃~+60 ℃ * *, suitable for harsh industrial environments.

The size is about 30 × 20 × 20cm, the weight is about 2kg, and it is installed in a standard card style.

Built in power distribution and bus arbitration simplify system wiring and expansion.

Electrical isolation between channels enhances signal anti-interference and system safety.

Compliant with international safety certifications such as CE and UL.

Discontinued production, the market is dominated by refurbished/second-hand spare parts.

The Westinghouse 3A99200G01 backplane, with its highly reliable bus architecture, strong compatibility, and industrial grade design, has become the core interconnect unit of the Ovation system controller rack, ensuring stable expansion and efficient operation of the system.
