Product Details Introduction

OUT-16/THK-2791 is a TOYOPUC 16 point MOSFET source type (+) universal digital output PLC module, compatible with PC10/PC3J series control systems.

Model name: OUT-16, form code THK-2791, belonging to TOYOPUC PC10/PC3J series.

Output type: MOSFET (+) universal (source type), optocoupler isolated.

Points: 16 points per module, 8 points per common terminal (COM).

Rated load voltage: DC5/12/24V.

Maximum load current: 1A/point, 4A/8 point group, 3.2A/COM.

Leakage current: ≤ 0.1mA when OFF.

Response time: ON/OFF switching ≤ 1ms, high-speed output.

Status indication: Each point is equipped with an LED, which lights up when turned on for easy diagnosis.

External connection: Detachable terminal block, allowing for quick module replacement after wiring.

Fuse: 6.3A/COM, overcurrent protection.

Working temperature: -20 ℃~+70 ℃, wide temperature industrial grade.

Humidity: 10%~95% RH (non condensing).

Certification: CE, UL, compliant with industrial safety standards.

Compatibility: Seamless integration with PC1G/PC3J CPU, backplane, and I/O modules.

Application: Control solenoid valves, relays, indicator lights, small actuators, suitable for machine tools, production lines, and automation equipment.

OUT-16/THK-2791 is the standard output unit of TOYOPUC system, with source output, high current carrying, high-speed response, and strong isolation as its core.

Product imag
