TEKTRONIX VX4240 waveform analyzer

TEKTRONIX VX4240 waveform analyzer

Product Details Introduction

TEKTRONIX VX4240 is a VXI bus based 12 bit 10MS/s waveform analyzer/digitizer module launched by Tektronix. It is designed for high-precision signal acquisition and analysis, with high integration and comprehensive functions.

Using a 12 bit A/D converter, with a maximum sampling rate of 10MS/s and a bandwidth of 5MHz, it accurately restores DC to high-frequency signals.

Built in INMOS T800 floating-point transputer processor, supporting real-time signal processing on the board.

Standard 256K word sampling memory, optional 512K word (01 option) or 1M word (02 option) expansion.

Supports differential/single ended input, AC/DC/ground coupling, 50 Ω input impedance, adaptable to multiple signal types.

Unique "virtual range" circuit, supporting 8 calibration ranges and custom ranges, flexibly adapting to different voltage signals.

Built in over 40 analysis functions, including key measurements such as FFT, THD, SNR, rise/fall time, and duty cycle.

Supports three triggering modes: pre trigger, center trigger, and post trigger, accurately capturing transient signals.

The input voltage range is 0.5V~100V, with a measurement accuracy of ± 0.2%, ensuring data reliability.

Supports VXIplug&play standards, compatible with Windows 95/NT and other systems, easy integration.

Equipped with semi-automatic calibration function, simplifying maintenance and precision calibration process.

Support external triggering and programmable clock, facilitating synchronous testing of multiple modules.

Adopting VXI C/D size standards, the structure is compact and compatible with standard VXI host racks.

Provide 2 BNC analog inputs and DB25 expansion interfaces to meet multi scenario connectivity requirements.

Support recording mode, which can continuously collect and store waveform data for a long time.

Industrial grade design, strong anti-interference, suitable for harsh testing environments such as laboratories and production lines.

TEKTRONIX VX4240, with its high-precision acquisition, rich onboard analysis, and compatibility with VXI bus, has become the core module of electronic testing, signal analysis, and automated testing systems, widely used in research and development as well as production line inspection scenarios.

Product imag
