TECHNO KR-505M Driver

TECHNO KR-505M Driver

Product Details Introduction

The TECHNO KR-505M is a 5-phase stepper motor driver produced by Suruga Seiki in Japan, designed specifically for precision positioning scenarios, with stability, reliability, and strong adaptability.

Adopting a bipolar pentagonal constant current drive method, it has high control accuracy and smooth operation.

Support dual step angle switching of 0.72 °/0.36 ° to meet different accuracy requirements.

Built in automatic current attenuation circuit effectively suppresses motor heating and extends service life.

The input signal adopts optocoupler isolation, which has strong anti-interference ability and is suitable for complex industrial environments.

The input power supply is AC100V ± 10% 50/60Hz, with a maximum of 350VA, suitable for standard industrial power supply.

The maximum driving current is 1.4A/phase, and the operating and stopping currents can be flexibly adjusted through a knob.

Supports two pulse input modes: 1 clock and 2 clock, compatible with multiple controller signals.

Equipped with self testing function, it can quickly detect the operating status of the driver and motor.

Provide origin position output signal for system positioning and closed-loop control.

Support high-speed/high torque mode switching and adapt to different load conditions.

Compact structure, with dimensions of approximately 170 × 130 × 39mm, making it easy to integrate and install equipment.

The working temperature range is 0-40 ℃, which meets the requirements of conventional industrial environments.

The weight is about 0.75kg, and the lightweight design reduces equipment load.

Suitable for 5-phase stepper motors from brands such as Tamagawa, with strong versatility.

The whole machine has high reliability and a one-year warranty period, suitable for long-term operation of precision equipment.

The TECHNO KR-505M driver, with its precise control, low heat generation, and high reliability, has become the preferred solution for stepper motor drives in fields such as semiconductors and precision machine tools.

Product imag
