HP 44723A Controller Module

HP 44723A is a high-speed digital I/O controller module designed specifically for the HP 3852A/3853A data acquisition system.

32 channel high-speed digital input/output control

Supports independent configuration of 16 inputs and 16 outputs

Single channel switching speed of up to 150000 times per second

Support external triggering and 16 bit digital mode capture

Input can achieve edge triggering and mode interruption functions

Equipped with output handshake to ensure stable control signals

Maximum input voltage range ± 24V DC

Open collector output, maximum load 40mA

Compatible with TTL levels and compatible with general digital circuits

The minimum pulse width can reach 355ns

Low power design, typical power consumption 0.7W

Perfectly compatible with HP 3852A/3853A hosts

Support cascading expansion of I/O quantity for multiple modules

Industrial grade stability, suitable for long-term automation control

The HP 44723A is designed specifically for high-speed measurement and control scenarios, with high speed, high stability, and strong scalability. It is the core component of automated testing and digital control systems.

Product imag
