INDRAMAT 109-525-1252A interface module

INDRAMAT 109-525-1252A interface module

Product Details Introduction

INDRAMAT 109-525-1252A is an RC8 interface/braking resistor board specifically designed for the INDRAMAT TDM series servo drives under Bosch Rexroth. It is used for servo axis braking resistor management and system interface. Its specific features are as follows:

The brand belongs to Bosch Rexroth INDRAMAT, which is the core auxiliary board of TDM series servo drives.

The official model is RC8, positioned as a brake resistor control and system interface module.

Suitable for INDRAMAT TDM series servo controllers, responsible for switching and protection control of braking resistors.

Integrated braking resistor switching circuit to achieve fast braking and energy absorption of servo motors.

Built in thermal protection and overcurrent detection ensure the safe operation of braking resistors and modules.

Provide internal signal interfaces for the system to achieve instruction and status interaction with the main control board.

Adopting a European style card insertion design, it can be directly plugged into the TDM series driver rack slot.

Industrial grade hardware design, suitable for high temperature and electromagnetic interference conditions inside the control cabinet.

The layout of onboard wiring terminals is standardized, and installation and wiring operations are easy.

Support multi axis braking resistor management and adapt to the braking requirements of medium power servo systems.

Equipped with self diagnostic function, it can provide feedback on brake circuit abnormalities and fault codes.

Compact structure, suitable for standard industrial cabinet installation, saving space.

The workmanship is sturdy, the anti vibration performance is good, and it meets industrial use standards.

Can directly replace faulty boards of the same model, with strong system compatibility.

 Product imag
