Anybus AB7006 Control Network Adapter

Anybus AB7006 Control Network Adapter

Product Details Introduction

AB7006 is an Anybus serial port to ControlNet protocol gateway that enables the interconnection of RS-232/422/485 devices with the ControlNet network, eliminating the need to modify device programs and enabling quick access to automation systems.

Function: Bi directional protocol conversion between serial port and ControlNet, mapping serial port data to ControlNet I/O, supporting protocols such as Modbus RTU/ASCII, DF1, etc.

Interface: BNC interface on the ControlNet side; Serial port side RJ45 interface, with a maximum speed of 5 Mbit/s.

Power supply: 24 VDC ± 10%, maximum power consumption of about 300 mA, with reverse connection and short circuit protection.

Installation: DIN rail installation (EN 50022), IP20 protection, compact size.

Configuration: Specialized software does not require programming, can be configured by importing EDS files, and supports dialing to set station addresses.

Compatibility: ControlNet specification certification, compatible with mainstream PLCs such as Rockwell and Siemens.

Performance: Subnet optoelectronic isolation, MTTF＞550, 000 hours, stable and reliable.

Environment: Working temperature 0-55 ℃, storage -40-85 ℃, humidity 0-95%, no condensation.

Typical: Serial devices such as batching scales, flow meters, and frequency converters are connected to the ControlNet production line.

ending

No modification required, easy to configure, stable and compatible, it is an efficient solution for serial devices to connect to the ControlNet network.

 Product imag
