Product Details Introduction

VMIVME-7486 is a 6U VMEbus PC/AT compatible processor module from Abaco Systems (formerly VMIC/GE Fanuc), based on the Intel 80486 architecture, suitable for industrial automation, embedded control, and data acquisition systems.

Processor: Intel 80486 series, standard 33MHz DX, optional 66MHz DX2 or lower SX version.

Cache: 8KB four-way group associated on-chip cache, high hit rate, close to zero waiting state.

Memory: Maximum 16MB 32-bit DRAM, supports single bank storage.

Display: Super VGA 1024 × 768 non interlaced resolution, onboard 1MB video DRAM.

Storage: Onboard floppy disk and IDE controller, supporting standard PC/AT disk format.

Communication: 2 RS-232C serial ports, 1 Centronics parallel port.

Interface: PC/AT keyboard interface, real-time clock with battery backup.

Bus: Complete VMEbus functionality, supporting real mode/protected mode memory access.

Byte exchange: Three way byte exchange hardware, compatible with small end/large end interfaces.

System compatibility: Supports DOS and Windows operating systems, and can be connected to PLC and upper computer networks.

Diagnosis: Hardware self-test and fault alarm, convenient for on-site maintenance.

Package: 6U VME standard size, compatible with industrial chassis.

Expansion: Optional functional modules such as Ethernet and flash drive.

Environment: Wide temperature design, suitable for harsh industrial sites.

Applications: industrial control, robotics, data acquisition, communication systems, etc.

ending

This module is based on PC/AT compatible architecture and VMEbus high-speed transmission, which is stable and reliable. It is a classic choice for upgrading old industrial systems and building new embedded projects.

 Product imag
