IC693APU301 axis positioning module

IC693APU301 axis positioning module

Product Details Introduction

IC693APU301 is the Motion Mate Single Axis Positioning Module (APM) of GE Fanuc 90-30 series PLC, designed for high-precision motion control of servo/stepper motors. It supports independent positioning and electronic gear synchronization, and can achieve high-speed closed-loop control without the CPU main cycle. It is the core component for precision positioning, point motion, and synchronous tracking scenarios.

Single axis independent control: dedicated single axis servo control, does not occupy PLC CPU resources, independently completes positioning calculations

Dual working mode: supports standard mode (point/speed control) and driven mode (electronic gear synchronization)

Up to 175kHz feedback: compatible with AB phase encoders, single channel up to 175kHz, suitable for high-precision encoders

Multiple Feedback Types: Supports multiple feedback types such as incremental encoders, TEMPOSONICS linear displacement sensors, etc

Can store 10 sets of programs: Built in non-volatile memory, can store 10 sets of motion programs, not lost in case of power failure

8 inputs and 4 outputs: Comes with 8 universal inputs and 4 outputs, used for logic such as limit, origin, and enable

Dual 24 pin high-density interface: connector A is connected to servo, connector B is connected to universal I/O and feedback, with wiring specifications

Compatible with MCM001 interface: can connect digital servo drives through Motion Mate MCM001 module

Multi module expansion: Embedded CPUs can support up to 3 blocks, while modular CPUs (331+) can support up to 8 blocks

LED status diagnosis: equipped with STAT, OK, AXIS POS and other indicator lights, real-time monitoring of operation and faults

Optoelectronic isolation protection: The signal is fully isolated from the internal circuit, resistant to industrial electromagnetic interference, and ensures stability

Wide temperature industrial design: Operating temperature range of * * -25 ° C~+70 ° C * *, suitable for harsh industrial environments

Standard single slot installation: compatible with 90-30 series PLC baseboards, supporting CPU, expansion, and remote base installation

Convenient software configuration: Parameters and programming can be completed through VersaPro and Logicmaster 90-30 software

Typical application scenarios: packaging machinery, material positioning, flying shear, electronic gears, single axis robots, precision assembly

ending

IC693APU301 is an ideal choice for achieving high-performance single axis motion control in GE 90-30 PLC systems due to its independent computation, high-precision positioning, flexible synchronization, and stable reliability. It is widely adapted to the precision positioning and synchronization control requirements of automated production lines.
