IC693APU300K high-speed counter module

IC693APU300K high-speed counter module

Product Details Introduction

IC693APU300K is a high-performance high-speed counter module designed specifically for GE Fanuc 90-30 series PLCs. It is designed to handle high-frequency pulse signals in industrial fields and has independent computing, precise counting, and real-time control capabilities. It can independently complete high-speed signal acquisition and logic response without the CPU main cycle, effectively improving system real-time performance and counting accuracy.

Equipped with a 32-bit independent processor, it can independently complete high-speed counting tasks without occupying PLC CPU resources

Provide 12 positive logic inputs, support 5VDC or 10-30VDC dual voltage mode, compatible with multiple pulse sensors

The maximum counting frequency is up to 200kHz, which can accurately capture high-speed pulse signals and meet high-frequency scenarios such as speed measurement and positioning

Configure 4 positive logic outputs, support open collector and push-pull outputs, can directly drive loads such as relays and solenoid valves

Supports multiple counting modes: single channel count up, count down, bidirectional count up and down, and dual channel difference count

Flexible configuration for 1-channel complex counter, 2-channel independent composite counter, or 4-channel basic independent counter

The input and output channels are fully optically isolated, effectively suppressing industrial electromagnetic interference, ensuring signal stability and module safety

Equipped with a detachable terminal board, convenient on-site wiring and maintenance, supporting hot plug operation

Built in LED status indicator light, real-time display of power, operation, faults, and the working status of each channel

Equipped with multiple protection mechanisms for overcurrent, reverse connection, and short circuit, the output circuit is equipped with 3A fuses to enhance reliability

Wide temperature industrial grade design, operating temperature range -40 ° C~+70 ° C, suitable for harsh industrial environments

Standard single slot size, compatible with GE 90-30 series PLC motherboard, flexible installation and easy expansion

Support parameter configuration and functional programming through programming software (VersaPro, Logicmaster)

Equipped with internal diagnostic function, it can monitor module status, signal abnormalities, and fault information in real time

Typical applications include turbine flow meters, high-speed speed measurement, precision positioning, material sorting, motion control, and other scenarios

ending

IC693APU300K, with its core advantages of high-speed response, independent operation, and stable reliability, has become an ideal module for high-speed pulse signal processing and precise counting control in industrial automation, widely adapting to various high-precision and high real-time industrial control scenarios.

 Product imag
