YB560100-EA S3 robot teaching pendant

YB560100-EA S3 robot teaching pendant

Product Details Introduction

ABB YB560100-EA S3 robot teaching pendant

YB560100-EA S3 is an industrial robot handheld programming operation terminal (Teach Pendant) produced by ABB (ASEA BROWN BOVERI). It is the core human-machine interaction component of ABB's early S3 series control system, used for robot manual control, program writing, trajectory teaching, and system debugging.

Model: YB560100-EA, series identification S3

Brand: ABB (Swedish/Swiss ABB Group)

Type: Industrial Robot Handheld Teaching Programmer

Adaptation system: dedicated to ABB S3, S3C, S3L, S4 early control systems

Core functions:

Manually control robot joint/coordinate system motion

Robot program creation, editing, modification, and storage

Trajectory teaching, parameter setting, I/O monitoring

System diagnosis, fault inquiry, status monitoring

Hardware features:

Equipped with monochrome/color LCD display screen (early mostly monochrome)

Film button+function shortcut key combination

Integrated emergency stop button, enable switch (safety device)

Mode selection switch (automatic/manual T1/T2)

Connect the robot control cabinet with cables

Industrial grade dust-proof, earthquake resistant, and anti-interference design

Communication: Special cable directly connected to ABB S3/S4 controller

Environment: Working temperature 0 ℃~45 ℃, humidity 5%~90%, no condensation

Application: Automated production lines for automobile manufacturing, welding, assembly, handling, spraying, etc

Status: Belonging to classic old models, currently mostly supplied as spare parts/maintenance/refurbishment

Weight: Approximately 1.45kg (3.2 pounds)

Warranty: Original/refurbished parts usually come with a 6-12 month warranty

In summary, YB560100-EA S3 is a handheld teaching pendant that comes standard with ABB S3 control systems. It is known for its stability, reliability, intuitive operation, and comprehensive safety protection. It was a key interactive component of early ABB industrial robot systems and is still used in the maintenance of a large number of old production lines today.
