SNAT617CHC is a core control board designed by ABB specifically for medium voltage transmission and chopper control scenarios, with part number 61037136. It is mainly used for high-power transmission systems such as ACS/ACC 617, to achieve chopper control, signal processing, and system communication.

Core specifications and features

Brand and model: ABB SNAT617CHC, part number 61037136

Product type: chopper control board/transmission control board

Applicable system: ABB ACS/ACC 617 series medium voltage frequency converter, high-power transmission device

core functionality

Precise chopper control, regulating voltage/current waveform

High speed signal acquisition and algorithm computation

Multi channel I/O processing and status feedback

Industrial communication interface to achieve system interconnection

hardware configuration

Industrial grade processor, supporting complex control algorithms

Multi channel analog/digital input/output, adaptive multi type signal

Communication interfaces include Ethernet, RS-485, PROFIBUS, etc

Power supply: Available in 24 VDC or 220 VAC versions

Physics and Environment

Size: Standard industrial control board size, suitable for installation in control cabinets

Working temperature: -20 ℃~+60 ℃, some models support a wide temperature range of -40 ℃~+80 ℃

Industrial grade anti-interference, optoelectronic isolation, suitable for harsh environments

reliability

Solid state design, fanless, supports 7 × 24-hour continuous operation

Built in fault diagnosis and protection functions to enhance system safety

Modular structure, easy to install, debug, and maintain

Application field

High power equipment for industries such as electricity, metallurgy, petrochemicals, and cement

Fan, pump, compressor, extruder, conveyor belt drive

Medium voltage transmission system, chopper control, high-precision speed regulation scenario

Functional Overview

As the control core of ABB's medium voltage transmission system, SNAT617CHC optimizes the voltage/current output waveform through chopper technology, combined with high-speed computing and communication capabilities, to achieve precise and stable control of the motor, while ensuring the long-term reliable operation of the system in complex industrial environments.

 Product imag
