AWCII 040 CPU module

AWCII 040 CPU module

Product Details Introduction

AWCII-040 (AWCII-040) is a high-performance VME bus CPU processor module launched by ADEPT (USA), designed specifically for the Adept MV series robot controller. As the main processor of the system, it provides high-speed computing and multi device communication capabilities.

Core specifications and features

Processor: Equipped with Motorola 68040 microprocessor, with a main frequency of 25MHz.

Architecture specification: Single slot 6U VME standard industrial bus module.

Memory: Comes standard with 4MB or 8MB DRAM (factory fixed, not upgradable on-site).

communication interface

1 Ethernet interface

1 RS-422 serial port

2-channel RS-232 serial port

Functional positioning: As the main computing core of the Adept MV controller, it performs motion control, logic processing, I/O scheduling, and system monitoring.

Physical characteristics: The size is approximately 26.1cm × 17.2cm × 2cm, and the weight is approximately 0.4kg.

Work environment: Industrial grade design, suitable for an automated production line environment with wide temperature range and high vibration.

System compatibility: Dedicated to ADEPT robot control system, supporting multi axis linkage and precision trajectory calculation.

Reliability: Fanless, solid-state circuit design, suitable for 7 × 24-hour continuous operation.

Application areas: Widely used in industrial robot scenarios such as electronic assembly, material handling, packaging, spot welding, etc.

Status: This model has been discontinued and is currently mainly circulated in the spare parts and second-hand market.

Functional Overview

This module is the computing heart of the ADEPT robot system, responsible for parsing motion instructions, executing control algorithms, managing external I/O, and achieving high-speed communication with the upper computer, teaching pendant, sensors, and servo drive through multiple serial ports and Ethernet, ensuring the accuracy, speed, and stability of robot actions.

 Product imag
