INICT03A Computer Transmission Module

INICT03A Computer Transmission Module

Product Details Introduction

INICT03A is the computer transmission module (ICT) of ABB Bailey Symphony/INFI 90 system, serving as a high-speed communication bridge between Infi Net/Cnet and the upper computer, enabling bidirectional data exchange and system monitoring.

Compatible with ABB Symphony and INFI 90 DCS systems, serving as a communication gateway between Infi Net/Cnet and the upper computer

The core function is high-speed data transmission, remote monitoring, and parameter configuration between computers and control systems

Standard configuration includes 2 RS-232-C serial ports (speed 50-19200bps optional) and 1 SCSI high-speed interface (4MB/s)

Memory configuration: 512KB ROM, 2MB RAM, supporting up to 30000 variable definitions

Backboard+5V DC power supply, typical power consumption of about 10W, supports ± 10% wide voltage

Single slot standard rack installation, supports hot swapping, online maintenance without interruption of operation

Industrial grade design, working temperature 0-60 ℃, humidity 5% -95% (no condensation), protection level IP20

Built in photoelectric isolation and data verification, strong anti-interference, ensuring stable and reliable transmission

Compatible with INFI 90 native protocol, can interface with external systems such as Modbus RTU/TCP, Profibus DP, etc

Support dual channel hardware redundancy, with a fault switching time of less than 10ms, ensuring uninterrupted communication

Built in diagnostics and status indicators for quick identification of communication anomalies

Jack board wiring method, anti vibration, firm contact, suitable for on-site working conditions

Compliant with industrial safety and electromagnetic compatibility standards such as CE and UL

Widely used for upper computer integration in large-scale process automation systems such as power, metallurgy, and chemical engineering

Low power consumption, fanless design, long lifespan, low failure rate, suitable for long-term continuous operation

This module is a key component of the DCS system upper computer integration, which is stable, efficient, and adaptable, and can meet the high reliability communication needs of industrial sites.

 Product imag
