ABB DSQC609 3HAC14178-1 power module

DSQC609 (3HAC14178-1, also known as PBSE5117) is a specialized 24V DC power module for ABB IRC5 series robots. It provides stable power supply for the core components of the controller (CPU, axis computer, communication board, I/O module) and is the basic power supply unit of the IRC5 control system.

Brand and model: ABB DSQC609, material number 3HAC14178-1, official name Power Supply Module.

Adaptation system: IRC5 series robot controller, compatible with all IRC5 models including IRB 120/140/2600/4600/6700.

Core function: Convert external AC input into stable 24V DC to power the internal core circuit of the controller; Equipped with voltage stabilization, filtering, multiple protections, and status monitoring.

Electrical specifications:

Input: 100-240V AC, 50/60Hz, wide voltage compatible

Output: 24V DC, rated current 2A, maximum power 48W

Efficiency: ≥ 90%, low heat generation, low power consumption

Protection function: Built in overvoltage, undervoltage, overload, short circuit, and overheating protection to ensure the safety of internal circuits.

Status indication: Onboard LED indicator light, displaying power supply normal, fault, and output status for quick diagnosis.

Installation method: IRC5 controller internal backplane slot direct insertion installation, modular design, supports quick replacement.

Physical parameters: size approximately 84.6 × 48 × 17.5mm, net weight 0.3kg, protection level IP20.

Environmental adaptation: Working temperature -20 ℃~+55 ℃, humidity 5% -95% (non condensing), resistant to industrial electromagnetic interference.

Certification standards: Passed CE, UL, CSA safety certifications, in compliance with industrial equipment safety regulations.

Product status: The IRC5 system comes standard with a core power module, which is still in production and is a commonly used spare part.

Application scenarios: Internal power supply for IRC5 controller, power supply for CPU/axis computer/communication board/I/O module, basic power supply guarantee for robot control system.

This module has the core advantages of wide voltage compatibility, high efficiency and stability, multiple protections, compact size, and easy installation, and is a key basic component for the stable operation of ABB IRC5 robot control system.
