DSQC313 3HAB22131 Sequence Measurement Module

DSQC313 3HAB22131 Sequence Measurement Module

Product Details Introduction

ABB DSQC313 3HAB2213-1 sequence measurement module

DSQC313 (3HAB2213-1) is a high-precision sequence measurement module dedicated to ABB robots, used for signal acquisition and real-time processing of force/torque/position, ensuring precise control of robots.

Brand and Model: ABB DSQC313, Model 3HAB2213-1, Robot SMB Measurement Board.

Core application: Collecting high-precision signals from force sensors, torque sensors, encoders, and other sensors.

Channel configuration: 8/16 analog inputs, compatible with multi-sensor parallel measurement.

Measurement accuracy: ± 0.01% full scale, 12/16 bit high-resolution.

Input range: -10V~+10V, compatible with industrial standard sensor signals.

Sampling rate: up to 1kHz, meeting real-time control requirements.

Communication interface: DeviceNet/CANopen, high-speed communication with robot controller.

Power supply: 24V DC, compatible with robot system power supply standards.

Size: 89mm × 48mm, compact design, saving installation space.

Weight: Approximately 0.1kg, easy to install.

Working temperature: -25 ℃~+85 ℃, suitable for harsh industrial environments.

Signal isolation: Channel isolation, strong anti-interference ability.

Status indication: LED displays running, fault, and communication status.

Application scenarios: ABB industrial robots, precision assembly, welding, handling, etc.

Spare parts attribute: Commonly used mature spare parts for robot systems, with strong compatibility.

DSQC313, with its high precision, reliability, and strong adaptability, has become the core module for precision measurement and control of ABB robots, ensuring accurate and efficient operation of industrial production.
