Delta 0190-26873 Data System Module

Delta 0190-26873 Data System Module

Product Details Introduction

Brand and model: Delta Tau (now Omron Automation) from the United States, material number 0190-26873, corresponding to the core model UMAC-CPCI Turbo CPU (603625-102A).

Core positioning: Turbo level CPU core module of UMAC series motion control system, responsible for multi axis real-time motion control and data processing.

System architecture: 3U modular design based on CPCI bus, compatible with UMAC rack, supporting multi axis collaboration and expansion.

Processor configuration: Equipped with high-performance Turbo PMAC DSP, with a main frequency of 80MHz, supporting high-speed servo loop operation.

Memory specifications: Built in 256k × 24 SRAM and 1M × 8 Flash, used for program execution, data caching, and firmware storage.

Communication interface: Standard configuration includes 100Mbps Ethernet and RS-232 serial port, supporting industrial bus extensions such as EtherCAT and MACRO.

Axis control capability: Single module supports multi axis servo/stepper control, expandable to 32 axis synchronization, suitable for high-precision motion scenes.

Servo performance: Built in PID+feedforward+notch filtering algorithm, servo sampling frequency ≥ 20kHz, dynamic response<1ms.

Encoder interface: Each axis supports 3-channel differential ABZ encoder, compatible with incremental and grating types, and suitable for single ended/differential signals.

Analog output: Each axis provides a 12 bit ± 10V analog output for driving servo amplifiers.

I/O resources: Integrate 32 universal digital I/O channels, support optoelectronic isolation, and adapt to industrial sensors and actuators.

Power supply specifications: 5V DC main power supply, ± 12V DC auxiliary power supply, compatible with industrial control system standard power supply.

Hardware protection: Industrial grade PCB design, metal shielding shell, anti electromagnetic interference, suitable for harsh industrial environments.

Application scenarios: High precision motion control fields such as semiconductor equipment, lithography machines, precision machine tools, robots, and automated production lines.

Compatible Replacement: It can directly replace UMAC-CPCI Turbo CPU modules of the same series (such as 603625-104), and the system is seamlessly compatible.

In summary, Delta Tau 0190-26873 (UMAC-CPCI Turbo CPU) is the core computing unit of UMAC motion control system, with Turbo level DSP computing power, multi axis high-precision synchronization, rich communication interfaces, and industrial grade reliability as its core advantages. It is a key module for high-end precision motion control.

 Product imag
