Product Details Introduction

Introduction to the Core of 1771-OD16 Isolation Output Module

The model is 1771-OD16, belonging to the Rockwell PLC-5 series 16 channel isolated AC output module.

Adopting solid-state bidirectional thyristor output, supporting zero crossing triggering, effectively reducing current surge.

Rated working voltage 120V AC, applicable range 74-138V AC, frequency 47-63Hz.

The maximum continuous output current of a single channel is 2A, and the total current of the module does not exceed 8A.

Equipped with electrical isolation between channels and between channels and backboards, with strong insulation performance and high safety.

Built in surge suppression protection circuit enhances module anti-interference and service life.

The off state has low leakage current, avoiding the problem of accidental triggering of low-power loads.

Each channel is equipped with independent LED indicator lights to display the output status in real-time.

Equipped with operation indicator lights and fuse alarm indicator lights for easy fault diagnosis.

Powered by a 5V DC backplane, it has low power consumption and stable and reliable operation.

Occupying one 1771 standard rack slot, the installation layout is compact.

Equipped with dedicated wiring arm, standardized wiring, and easy maintenance.

Compatible with PLC-5 full series controllers and 1771 series racks.

Working temperature range of 0-60 ° C, suitable for various industrial site environments.

Through UL, CE and other industrial certifications, it is suitable for control systems with high isolation requirements.

The above are the complete core parameters of the 1771-OD16 isolated output module, which can be directly used for product introduction, technical documentation, and project selection reference.

1771-OD16 Product imag
