1769-IA16 input module

1769-IA16 input module

Product Details Introduction

Introduction to the Core of 1769-IA16 Input Module

The model number is 1769-IA16, belonging to the Rockwell Compact I/O series 16 point AC digital input module.

Mainly used to collect signals from on-site 120V AC switches, buttons, and sensors.

Rated input voltage 100/120V AC, operating voltage range 79-132V AC.

The input frequency supports 47-63Hz and is compatible with industrial standard power supply.

The single module has a total of 16 input channels and adopts a grouped internal common ground structure.

Input conduction current of 5-12mA, turn off leakage current not exceeding 2.5mA.

The input response time is 20ms, which meets the requirements of conventional industrial control response.

There is electrical isolation between the channel and the backplane, and the insulation and voltage resistance meet industrial safety standards.

Powered by a 5V DC backplane, it has low power consumption and stable operation.

Each channel is equipped with independent LED indicator lights to visually display the on/off status.

Use detachable terminal blocks for easy wiring, maintenance, and replacement.

Supports DIN rail installation and panel installation, compatible with standard electrical control cabinet layout.

Compatible with CompactLogix, Compact GuardLogix, and MicroLogix 1500 controllers.

Working temperature range of 0-60 ° C, suitable for various industrial site environments.

Through multiple industrial certifications such as CE and UL, reliability and safety are guaranteed.

The above are the complete core parameters of the 1769-IA16 input module, which are applicable for product introduction, technical selection, and project data writing.

1769-IA16  Product imag

1769-IA16 ontroller Module
