TEL Tokyo Electron 381-642446-1 Connection Board is an electronic connection module used inside semiconductor manufacturing equipment, mainly used to achieve physical connection and distribution of signals, power or communication lines between different control units, circuit boards or functional modules. This component is part of the internal structured cabling system of the device, and is particularly critical in situations where the device has high integration and complex modular design.

1、 Basic Product Information

Product model: 381-642446-1

Product Name: Connection Board/Interface PCB

Manufacturer: Tokyo Electron Ltd. (TEL)

Product Category: Internal Communication/Signal Interface Board

2、 Core functions

Signal transmission bridge

Concentrate, convert, or distribute signals from different subsystems such as controllers, I/O modules, and sensors.

power distribution

Provide low-voltage power supply paths (such as+5V,+12V,+24V, etc.) for downstream modules (such as small control boards, driver boards).

Signal integration and organization

Standardize the layout of cables inside complex equipment, and centrally process them through connection boards to reduce interference and improve maintainability.

Multi interface integration

Multiple connection methods may be integrated on a single board, including pin headers, terminal blocks, flat cable slots, FFC/FPC connectors, etc.

3、 Typical application areas

Main architecture of semiconductor equipment control

As a relay hub between the main control board, I/O cards, and various sub modules, it is commonly used in TEL equipment such as Etcher, CVD, coating and developing machines.

Signal relay and distribution node

Introduce input signals from peripheral devices such as sensors, actuators, and thermostats, and forward them to the corresponding control module.

Standard connection platform between modules

In the TEL modular structure, it is used to connect CPUs, communication modules, digital input boards, relay output boards, etc.

Debugging and maintenance auxiliary interface

Some connection boards integrate status indicator lights, jumper areas, and test ports for easy troubleshooting and signal testing.

Product imag
