Product Details Introduction

Product model: 2L81-050085-51

Product Name: Analog Input Electronic Module

Manufacturer: Tokyo Electron Ltd. (TEL)

Component category: Signal acquisition module/Analog input module

1、 Product Overview:

2L81-050085-51 is an electronic module used in Tokyo Electron equipment for collecting and processing analog signals. Its main function is to accurately sample, convert, and transmit analog signals from various sensors (such as temperature, pressure, flow rate, position, etc.) for subsequent processing and judgment by the equipment control system.

This module is a key component for implementing fine process control and process monitoring in equipment.

2、 Main functions:

Function module description

Analog signal acquisition supports multi-channel analog input, collecting analog signals such as voltage and current

The signal conversion is equipped with a high-precision analog-to-digital converter (ADC), which converts analog signals into digital signals

Signal conditioning includes circuits such as filtering, amplification, and isolation to ensure stable and reliable signals

Sampling rate control can configure sampling frequency to meet different process control requirements

The communication interface transmits digital signals to the main control system through a bus or interface

3、 Technical parameters (based on the general specifications of TEL analog input module):

Project parameters or description

Input type: Voltage input (typical 0-10V), current input (4-20mA)

Multiple input channels, commonly ranging from 8 to 16 channels

Resolution 12 bit or 16 bit ADC

Sampling rate can reach several kHz, supporting high-speed sampling

Signal isolation optocoupler or magnetic isolation protection input port

High input impedance, suitable for sensor signal access

The power requirement is 5V, 12V, or 24V DC, depending on the specific equipment requirements

Connection method: plug-in connector or backplane interface
