TEL Tokyo Electron 2L81-050032-V2 processor board

TEL Tokyo Electron 2L81-050032-V2 processor board

Product Details Introduction

Product model: 2L81-050032-V2

Product Name: Processor Board

Manufacturer: Tokyo Electron Ltd. (TEL)

Component Category: Embedded Control Processing Unit/Core Processing Module

1、 Product Overview:

2L81-050032-V2 is a processor board used in Tokyo Electron semiconductor equipment, responsible for executing key tasks such as internal control logic calculations, data processing, instruction scheduling, and system communication.

This board is usually equipped with an embedded CPU or microcontroller, serving as the "brain" of the device control system, responsible for multitasking scheduling and real-time control requirements, ensuring the precise operation of the equipment process flow.

2、 Main functions:

Function module description

Control instruction processing, parsing, and execution of process control program instructions

Data collection management processes sampled data from sensors and input modules

Output control execution module's action command output

Communication coordination and communication with the upper control system and internal modules

Running monitoring and monitoring system operation status, detecting abnormal alarms

3、 Technical parameters (refer to the design of a general TEL processor board):

Typical parameters or descriptions of the project

Processor type: Embedded CPU/MCU (such as ARM architecture or TEL custom chip)

Memory with built-in Flash and RAM for program and data storage

The input interface supports digital/analog input, including sensor signals

The output interface supports multiple DO, analog outputs, and PWM control signals

The communication protocol supports RS232, RS485, CAN, Ethernet, or TEL proprietary protocols

Common power requirements include 24V DC power supply and support for power management

Installation form: plug-in or rack mounted, convenient for maintenance and replacement

Product imag
